Cisco Compatible SFP 2.5GBASE-EX 1310nm 40km DDM Duplex LC/UPC SMF Optical Transceiver Module

SFP-2GE-LX/H40
The SFP-2GE-LX/H40 provides data transfer rates of up to 2.5Gbps and supports data transmission distances of up to 40km. The module uses an SFP interface and has a user-friendly design for easy installation, upgrade and replacement. It is suitable for a variety of data centers, switches, storage networks and servers and other communication occasions, is an indispensable part of the communication network.

Product Highlights
*Tested in Targeted Switch for Superior Performance, Quality, and Reliability
*Hot Pluggable SFP MSA Compliant
*Digital Optical Monitoring Capability for Strong Diagnostic Capabilities
*BOX - Support Real-time Configuration
*Compliant to IEEE Std 802.3
*RoHS-6 compliant (lead-free)
Quantity:
Contact Now
add to cart

Brand Compatible With 2.5GBASE-EX SFP Transceiver Module(SFP Double Fiber Single-Mode,2.5G,1310nm,40km,LC,DDM)

Cisco compatible 2.5GBASE-EX SFP transceiver supports up to 40km link lengths over single-mode fiber (SMF) using a wavelength of 1310nm via an LC connector. Each 2.5g network sfp fiber module is individually tested to be used on a series of Cisco switches, routers, servers, network interface card (NICs) etc.
Featuring low power consumption, the hot swappable 2.5g network sfp fiber module is ideal for Internet Service Provider (ISP) Gigabit Ethernet communication links, Enterprise LAN & SAN Networks, Data Center LAN & SAN Networks and other optical links.

Product Details

Part Number:SFP-2GE-LX/H40
Description:SFP optical module dual-fiber single-mode, 2.5G, 3.3V, LC, working temperature 0~70℃, 1310nm, 40KM, DDM
Compatible with:H3C, HW, Cisco, HP, etc

Data Rate
Module Type
Distance
Wavelength
Interface
Temperature
DDM
2.5Gb/s
SFP
40KM
1310nm
LC
0~70℃
Yes



the 2.5g network sfp fiber has a standard SFP interface for connecting to other communication devices

SFP-2GE-LX/H40 is a high-performance 2.5g network sfp fiber module designed specifically for fiber optic communications.   The use of single-mode fiber for data transmission can provide up to 2.5Gbps data transmission rate, while having excellent stability and reliability, is an excellent fiber optic communication solution. Whether enterprise networks or data centers, 2.5g network sfp fiber modules are indispensable devices that can meet the needs of high-speed data transmission in different application scenarios, so that enterprises can operate more efficiently.

The 2.5g network sfp fiber module can achieve up to 40km of data transmission distance, at the same time, also has a digital diagnostic monitoring function, can manage and monitor the module Settings. The 2.5g network sfp fiber module supports two-way data transmission, which can not only receive data, but also transmit data signals to meet the needs of high-speed communication.

The 2.5g network sfp fiber module has a user-friendly design and uses a standard SFP interface for easy connection to other communication devices. The 2.5g network sfp fiber module can also meet the communication needs of higher rates. Moreover, the device also has a hot swap function, which is convenient to upgrade and replace the device, bringing a more convenient user experience.

In addition, our 2.5g network sfp fiber modules also have good adaptability, can be widely used in various types of data centers, switches, storage networks and servers and other communication occasions. Combined with the performance, stability and reliability of this product, we offer a high quality fiber optic communication product, including 2.5g network sfp fiber modules.

the 2.5g network sfp fiber has a standard SFP interface for connecting to other communication devices
In short, the 2.5g network sfp fiber module has the advantages of high-speed data transmission, long-distance support, digital diagnostic monitoring and easy connection.  The emergence of this 2.5g network sfp fiber module is expected to greatly promote the development and application of optical fiber communication technology, making it an ideal solution for a range of high-speed networking applications.

Specifications

Model number
SFP-2GE-LX/H40
Brand
Firstoptic
Form Factor
SFP
Max. Data Rate
2.5Gbps
Wavelength
1310nm
Max. Cable Distance
40km
Connector
Duplex LC
Media
SMF
Transmitter Type
DFB
Receiver Type
PIN
TX Power
 0 ~ 3dBm
Receiver Sensitivity
< -17dBm
DDM/DOM
Supported
Commercial Temperature Range
0 to 70°C (32 to 158°F)
Protocols
IEEE Std 802.3, FC-PI 13.0, SFP MSA(INF-8074i) Compliant
Warranty
Years

Certification system

the 2.5g network sfp fiber has a standard SFP interface for connecting to other communication devices        the 2.5g network sfp fiber has a standard SFP interface for connecting to other communication devices        the 2.5g network sfp fiber has a standard SFP interface for connecting to other communication devices        the 2.5g network sfp fiber has a standard SFP interface for connecting to other communication devices

Please Note: Installing a third party transceiver does not void your network equipment warranty. Network equipment manufacturers all have guidelines stating that warranty support on their products will not be affected.

Features

Before shipping, we conduct rigorous product testing, including the testing of 2.5g network sfp fiber modules, to ensure that every product meets the high quality standards.   We are committed to providing the most reliable and highest quality 2.5g network sfp fiber communication products, to bring excellent performance and stability to our customers.

the 2.5g network sfp fiber has a standard SFP interface for connecting to other communication devicesTest Equipment
the 2.5g network sfp fiber has a standard SFP interface for connecting to other communication devicesCompatible Test
the 2.5g network sfp fiber has a standard SFP interface for connecting to other communication devicesQC Test


High Compatibility for all Brands

The company sells a full line of 2.5g SFP optical module optical fiber products compatible with all major brands of equipment.
