3M Fiber Optical Patch Cord, SC UPC to SC UPC, Simplex, 1 Fiber, Single Mode(OS2), Riser (OFNR), 2.0mm, Tight-Buffered, Yellow

SC/UPC-SC/UPC SM 9/125 G652D SX 2.0mm LSZH Yellow 3M

Fiber optical patch cord is It is used to make a jump wire from the device to the optical fiber wiring link. It has a thick protective layer, which is generally used in the connection between the optical end machine and the terminal box, and is applied in some fields such as optical fiber communication system, optical fiber access network, optical fiber data transmission and local area network.

Product Highlights
*G.657.A1 Bend Insensitive Fiber & 10mm Min. Bend Radius
*Precision Zirconia Ferrule Connectors Ensure Low Loss
*Riser (OFNR) Jacket for Vertical and Floor-to-floor Installations
*Color-Coded Cable Jacket for Easy Identification
*Ideal for Unidirectional Data Transmission

Quantity:

Contact Now

add to cart

Fiber Patch Cable, SC UPC to SC UPC, Simplex, 1F, OS2, Riser (OFNR), 2.0mm

OS2 simplex SC to SC patch cord is engineered for high-density patching environments where quick installation and easy management are essential. This OS2 simplex SC to SC supports 1G to 400G transmission with low attenuation across extended distances.

With push-pull SC connectors, OS2 simplex SC to SC enables rapid deployment in telecom rooms and distribution frames. Choose OS2 simplex SC to SC for structured cabling, data center patching, and high-density fiber management.

Learn more about fiber connector types in our guide.

Specifications

Product Name	Fiber Optical Patch Cord	Brand	Firstoptic
Connector A	LC UPC Simplex	Connector B	LC UPC Simplex
Fiber Count	1 Fiber	Fiber Grade	G.657.A1 (Compatible with G.652.D)
Fiber Mode	OS2 9/125μm	Wavelength	1310/1550nm
RoHS Compliancy Status	Compliant	Cable Type	Tight-Buffered
Cable Outside Diameter (OD)	2.0mm	Cable Jacket	Riser (OFNR)
Min. Bend Radius (Optical Fiber)	10mm	Min. Bend Radius (Fiber Cable)	10/5D (Dynamic/Static)
Connector Durability	1000 times	Tensile Strength (Long/Short Term)	60/100N
Insertion Loss	≤0.3dB	Return Loss	≥50dB
Attenuation at 1310 nm	0.36dB/km	Attenuation at 1550 nm	0.22dB/km
Operating Temperature	-20 to 70°C (-4 to 158℉)	Storage Temperature	-40 to 80°C (-40 to 176℉)

The OS2 simplex SC to SC single-mode patch cord features a uniform SC/SC simplex interface, designed for point-to-point single-fiber applications with these key characteristics:

1. Secure Push-Pull Retention
The simplex SC connector's push-pull latching mechanism ensures reliable single-fiber connections with easy operation, making this patch cord dependable for unidirectional signal transmission in mainstream optical distribution systems.

2. High-Density Simplex Operation
Its straightforward push-pull design allows for quick and precise single-fiber insertion and removal while maintaining excellent ferrule alignment, establishing it as a practical and efficient choice for high-density rack and panel installations.

3. Low Insertion Loss Performance
With precision ceramic ferrule and OS2 single-mode fiber, it ensures ≤0.3dB insertion loss and ≥40dB return loss, providing reliable single-fiber connectivity for 1G/10G/25G applications in access networks and data centers.

4. Clear Simplex Identification
Standardized connector body with distinctive square shape and color coding prevents installation errors, ensuring optimal reliability in single-fiber data transmission links and telecommunications access networks.

1. Technical Standards & Compatibility

Compliant with mainstream optical distribution standards widely adopted in access networks, passive optical networks (PON), and fiber termination fields.
Supports reliable simplex connectivity in telecommunications infrastructure, data center patching, and environments where robust push-pull mating is preferred.

2. Typical Application Scenarios

Central Office & ODF Patching: Standard connections within optical distribution frames (ODFs) and telecom central offices for cross-connecting feeder and distribution cables.
Access & PON Network Infrastructure: Widely deployed in FTTx cabinets, PON splitters, and fiber termination points for stable and repeatable simplex connections.
Enterprise & Data Center Links: Serves as reliable cabling for equipment with SC ports, such as media converters, older switches, and fixed-configuration devices in racks.

we offer high quality simplex lc fiber patch cable that can provide customers with fast and reliable network transmission services.

Build a Stable and Robust Optical Fiber Network

High quality tightly buffered cables protect the fiber core and increase the strength and durability of the fiber.

we offer high quality simplex lc fiber patch cable that can provide customers with fast and reliable network transmission services.

Low insertion loss

high plug‑cycle durability; stable performance (<0.2 dB variation); seamless fiber alignment for reliable interchangeability.

Color-Coded Cable Sheathing for Easy Identification

The sheath color of fiber optical patch cord is usually defined by the fiber type and may vary depending on the mode and performance level.

Standardized Production

Multiple processes, strict screening, quality assurance.

Fine grinding
To ensure that the center of the optical fiber grinding offset, the surface of the optical fiber without defects, the size of the end curvature radius and other technologies meet the standard

Insertion/return loss detection
Insertion loss ≤0.3dB, return loss ≥50dB

End detection
End geometry test to ensure that the end curvature radius vertex offset, fiber height meets the standard

Meet the Various Installation Requirements

Fiber optical patch cords are used in optical fiber communication room, local area network (LAN), optical fiber data transmission, optical fiber into the home, and so on.

we offer high quality simplex lc fiber patch cable that can provide customers with fast and reliable network transmission services.

Optical fiber communication room Local area network (LAN)

we offer high quality simplex lc fiber patch cable that can provide customers with fast and reliable network transmission services.

Optical fiber data transmission Fiber to the home (FTTH)
