3M Fiber Optical Patch Cord, FC UPC to FC UPC, Simplex, 1 Fiber, Single Mode(OS2), Riser (OFNR), 2.0mm, Tight-Buffered, Yellow

FC/UPC-FC/UPC SM 9/125 G652D SX 2.0mm LSZH Yellow 3M

Fiber optical patch cord is It is used to make a jump wire from the device to the optical fiber wiring link. It has a thick protective layer, which is generally used in the connection between the optical end machine and the terminal box, and is applied in some fields such as optical fiber communication system, optical fiber access network, optical fiber data transmission and local area network.

Product Highlights
*G.657.A1 Bend Insensitive Fiber & 10mm Min. Bend Radius
*Precision Zirconia Ferrule Connectors Ensure Low Loss
*Riser (OFNR) Jacket for Vertical and Floor-to-floor Installations
*Color-Coded Cable Jacket for Easy Identification
*Ideal for Unidirectional Data Transmission

Quantity:

Contact Now

add to cart

Fiber Patch Cable, FC UPC to FC UPC, Simplex, 1F, OS2, Riser (OFNR), 2.0mm

The OS2 simplex FC to FC fiber patch cable delivers reliable point-to-point connectivity for data centers and telecom rooms. This OS2 simplex FC to FC cable supports 1G to 400G transmission over extended distances with low attenuation performance.

Featuring bend-insensitive fiber, the OS2 simplex FC to FC patch cord enables robust installation in high-vibration environments. The OS2 simplex FC to FC single mode patch cord maintains optimal signal integrity through secure threaded coupling. Designed for durability, the OS2 simplex FC to FC solution ensures long-term stability in demanding optical infrastructure. With its vibration-resistant construction, the OS2 simplex FC to FC connector system provides reliable performance in test, measurement, and industrial applications.

Learn more about fiber connector types in our guide.

Specifications

Product Name	Fiber Optical Patch Cord	Brand	Firstoptic
Connector A	LC UPC Simplex	Connector B	FC UPC Simplex
Fiber Count	1 Fiber	Fiber Grade	G.657.A1 (Compatible with G.652.D)
Fiber Mode	OS2 9/125μm	Wavelength	1310/1550nm
RoHS Compliancy Status	Compliant	Cable Type	Tight-Buffered
Cable Outside Diameter (OD)	2.0mm	Cable Jacket	Riser (OFNR)
Min. Bend Radius (Optical Fiber)	10mm	Min. Bend Radius (Fiber Cable)	10/5D (Dynamic/Static)
Connector Durability	1000 times	Tensile Strength (Long/Short Term)	60/100N
Insertion Loss	≤0.3dB	Return Loss	≥50dB
Attenuation at 1310 nm	0.36dB/km	Attenuation at 1550 nm	0.22dB/km
Operating Temperature	-20 to 70°C (-4 to 158℉)	Storage Temperature	-40 to 80°C (-40 to 176℉)

The OS2 simplex FC to FC single-mode patch cord features a uniform FC/FC simplex interface, designed for point-to-point single-fiber applications with these key characteristics:

1. Secure Threaded Retention
The simplex FC connector's threaded coupling mechanism ensures a vibration-resistant and highly reliable single-fiber connection, making this patch cord dependable for critical unidirectional signal transmission in test, measurement, and high-stability systems.

2. High-Stability Simplex Operation
Its threaded design allows for exceptionally secure single-fiber mating with positive lock, maintaining superior ferrule alignment even in demanding environments, establishing it as the preferred choice for vibration-prone and precision simplex installations.

3. Low Insertion Loss Performance
With precision ceramic ferrule and OS2 single-mode fiber, it ensures ≤0.3dB insertion loss and ≥50dB return loss, providing stable and reliable single-fiber connectivity for high-speed applications up to 400G in laboratory and telecom core environments.

4. Clear Simplex Identification
Standardized metal connector body with distinct threaded interface prevents incorrect mating, ensuring optimal reliability and performance in critical single-fiber data transmission links and precision optical networks.

1. Technical Standards & Compatibility

Compliant with high-precision and test equipment standards, including requirements for stable, low-reflection connections in measurement and core network environments.
Supports simplex connectivity in laboratory setups, test & measurement systems, and high-vibration applications where threaded coupling ensures superior stability.

2. Typical Application Scenarios

Test & Measurement Bench Links: Essential connections between optical test equipment (OTDRs, light sources, power meters) and devices under test, ensuring repeatable and stable results.
Telecom Core & Transport Networks: Used in central office transport equipment, certain ODFs, and high-stability links where vibration resistance and low back-reflection are critical.
High-Reliability Industrial & Broadcast: Serves in broadcast video, medical imaging, or industrial process control systems where secure, non-slip simplex fiber connections are mandatory.

we offer high quality simplex lc fiber patch cable that can provide customers with fast and reliable network transmission services.

Build a Stable and Robust Optical Fiber Network

High quality tightly buffered cables protect the fiber core and increase the strength and durability of the fiber.

we offer high quality simplex lc fiber patch cable that can provide customers with fast and reliable network transmission services.

Low insertion loss

high plug‑cycle durability; stable performance (<0.2 dB variation); seamless fiber alignment for reliable interchangeability.

Color-Coded Cable Sheathing for Easy Identification

The sheath color of fiber optical patch cord is usually defined by the fiber type and may vary depending on the mode and performance level.

Standardized Production

Multiple processes, strict screening, quality assurance.

Fine grinding
To ensure that the center of the optical fiber grinding offset, the surface of the optical fiber without defects, the size of the end curvature radius and other technologies meet the standard

Insertion/return loss detection
Insertion loss ≤0.3dB, return loss ≥50dB

End detection
End geometry test to ensure that the end curvature radius vertex offset, fiber height meets the standard

Meet the Various Installation Requirements

Fiber optical patch cords are used in optical fiber communication room, local area network (LAN), optical fiber data transmission, optical fiber into the home, and so on.

we offer high quality simplex lc fiber patch cable that can provide customers with fast and reliable network transmission services.

Optical fiber communication room Local area network (LAN)

we offer high quality simplex lc fiber patch cable that can provide customers with fast and reliable network transmission services.

Optical fiber data transmission Fiber to the home (FTTH)
